Description
The chevron reticle is designed to be zeroed using the tip at 100 meters. The width of the chevron at the base is 5.53 MOA which is 19 in. at 300 meters. This allows range estimation for silhouette targets. Features dual illumination (Fiber optics provides daylight illumination and tritium illuminates reticle at night). The ranging reticle is calibrated for 5.56(.223 cal) flattop rifles out to 800 meters.
Length x Width x Height: 5.98 in x 2 in x 2.3 in (151.89mm x 50.8mm x 58.42mm)
Weight: 14.9 oz. (422.41g)
Magnification: 4x
Objective Size: 32mm
Reticle Pattern: Chevron
Day Reticle Color: Amber
Night Reticle Color: Amber
Bullet Drop Compensating (BDC): Yes
Caliber: .223 / 5.56
Illumination Source: Fiber Optics & Tritium
Power Source: Fiber Optics & Tritium
Eye Relief: 1.5 in. (38.1mm)
Exit Pupil: 0.32 in. (8.13mm)
Field of View (degrees): 7°
Field of View (feet): 36.8 ft. @ 100 yds. (12.27m @ 100m)
Mount: Flattop Thumbscrew Mount (TA51)
Housing Material: Forged Aluminum
Finish: Matte Black
Submersion Depth: -66 ft. (-20m)
